Description
Technical Parameters
- Resistance at 25℃(Ω) (DC) 8-20
- Resistance at 25℃(Ω) (AC) 100-300
- Material Stainless
- Rated Voltage 72V/230V
- Max Voltage 90V/265V
- Withstand Voltage (V) 270V/10min(230V)
- Insulating withstand voltage Leak current≤10mA
- Inrush Current(A) (AC) ≤25
- Surface Temp. (℃) 240±10
- Power (W) 1500±10%
- Power (W) 1100±10%
- Length (mm) 420±2
- Diameter (mm) φ35±0.5
