ALGO Master Pack 3 – 3" Submersible Pump, Motor & Accessories Kit
The ALGO 3" Master Pack 3 is a complete submersible borehole pumping package designed to provide reliable water delivery while combining the pump, motor, control equipment and essential installation accessories into one convenient solution.
Powered by a 0.75 kW (1 HP) motor, the Master Pack 3 operates on 230V single-phase, 50Hz power and features a 27-stage pump capable of delivering a maximum head of approximately 115 metres.
Key Features
-
Complete 3" submersible pump and motor package
-
0.75 kW / 1 HP power rating
-
Single-phase 230V, 50Hz operation
-
2900 rpm operating speed
-
27-stage pump configuration
-
Maximum head of approximately 115 m
-
Maximum flow of up to 2.7 m³/h
-
1¼" outlet connection
-
Supplied with control box
-
Includes cable, safety rope, base plate and adaptors
-
Convenient all-in-one borehole pumping solution
What's Included
-
3" Submersible Pump
-
Submersible Motor
-
Control Box
-
100 m Submersible Cable
-
110 m Safety Rope
-
Aluminium Cast Base Plate
-
2 × Adaptors
Technical Specifications
| Specification | Details |
|---|---|
| Model | Master Pack 3 |
| Pump Model | 3MP3 |
| Nominal Diameter | 3" |
| Stages | 27 |
| Power | 0.75 kW / 1 HP |
| Voltage | 230V |
| Phase | Single Phase |
| Frequency | 50Hz |
| Speed | 2900 rpm |
| Outlet Size | 1¼" |
| Maximum Head | 115 m |
| Maximum Flow | 2.7 m³/h |
| Cable Length | 100 m |
| Safety Rope Length | 110 m |
Performance
| Flow Rate | Head |
|---|---|
| 0 m³/h | 115 m |
| 0.3 m³/h | 114 m |
| 0.6 m³/h | 112 m |
| 0.9 m³/h | 110 m |
| 1.2 m³/h | 104 m |
| 1.5 m³/h | 97 m |
| 1.8 m³/h | 88 m |
| 2.1 m³/h | 77 m |
| 2.4 m³/h | 65 m |
| 2.7 m³/h | 49 m |
Applications
Ideal for:
-
Residential borehole water supply
-
Household water systems
-
Garden and irrigation water supply
-
Water transfer applications
-
Deeper borehole applications
-
General-purpose borehole pumping
The ALGO 3" Master Pack 3 provides the highest head performance in the 3" Master Pack range, making it a practical complete solution for borehole installations requiring increased pumping head while retaining a compact 3" configuration.
